Our supporting materials consist of three main product categories: substrate resin, adhesion promoter and anti-sticking agent.
get in touch
Product Description
Substrate Resin
It is a UV-curable acrylate-based optical resin, specially developed for the fabrication of sub-masters via nanoimprint lithography. Featuring excellent filling performance, it can precisely replicate the micro/nano structures of the master template.
Adhesion Promoter
This product effectively improves the adhesion between nanoimprint resin and various substrates including glass, silicon wafers and resins. It is compatible with both spin-coating and spray coating processes.
Anti-sticking Agent
It can form a nano-scale anti-adhesion coating on the surface of silicon-based and glass molds. It delivers outstanding performances such as excellent anti-sticking property, easy demolding and convenient cleaning.
Technical Parameters
Substrate Resin
Status
Test Item
Units
NPR2103E
Test Method
Before Curing
Viscosity
cps
200-400
Viscometer at 25℃
Solid Content
%
>99
Solid Content Tester
Curing Conditions
Curing Energy
/
UV-LED 365nm，200mw/cm²
Curing Process
Spin Coating
/
1000rpm/S，45S
Baking
/
–
–
After Curing
Water Contact Angle
。
＞105
Water Contact Angle Tester at 25℃
Light Transmittance
%
＞99
Spectrophotometer (365 nm)
Haze
%
0.50±0.05%
Haze Meter
Hardness
Shore D
51D
Shore D Durometer
Abrasion Resistance
–
–
–
Applicable Substrates
–
–
–
–
Adhesion Promoter
Status
Test Item
Units
NP1301B
DT–10–2
Test Method
Before Curing
Viscosity
cps
<5
1~3
Viscometer
Solid Content
%
–
3±0.5
Solid Content Tester
Curing Conditions
Curing Energy
/
–
–
–
Curing Process
Spin Coating
/
4000rpm, 30s
2500rpm, 35s（＜100nm）
–
Baking
/
80℃, 3mins (Hotplate)
70℃, 2 mins
(Hot Plate or Oven)
–
After Curing
Water Contact Angle
。
–
–
–
Light Transmittance
%
–
–
–
Haze
%
–
–
–
Hardness
Shore D
–
–
–
Abrasion Resistance
–
–
–
–
Applicable Substrates
–
–
Glass, Silicon Wafers
Resin wafers
–
Anti-sticking Agent
Status
Test Item
Units
NP1302A
Test Method
Before Curing
Viscosity
cps
–
–
Solid Content
%
0.5-0.6
100℃1h
Curing Conditions
Curing Energy
/
–
–
Curing Process
Spin Coating
/
Post Spin Treatment 80℃ 2h/ 150℃ 1h
Baking
/
–
–
After Curing
Water Contact Angle
。
≥112
Water Contact Angle Tester
Light Transmittance
%
–
–
Haze
%
–
–
Hardness
Shore D
–
–
Abrasion Resistance
–
≥1000
1kg Wear Tester
Applicable Substrates
–
–
Silicon Wafer, Glass, Metal
